BWP Flush Doors from the house of Architwood are made from selected pinewood frames and evenly sized batons. Our high-density block board doors provide excellent insulation against dust, heat and sound. Made from quality, imported timber, they possess high resistivity to borers and termites.


S.No. Test IS : 2202 Requirements Architwood Results
1. Moisture Content (%) 10 - 12
 11
2. Flatness of Shutter
"(twist, cupping and warping)"		 not more than 1 mm 0.5mm
3. Local Planess
(surface smoothness)		 not more than 0.5 mm 0.3mm
4. Impact Indentation not more than 0.2 mm by a weight of 0.5 kg Pass
5. Flexure Resistance  (residual deflection) not more than 2 mm 1.1mm
6. Edge Loading
a) Residual deflection
b) Lateral buckling		 not more than 0.2 mm
not more than 1.5 mm		 0.15mm
0.08mm
7. Shock Resistance no visible damage after 25 blows of 5 kg Pass
8. Buckling Resistance
a) Initial deflection
b) Residual deflection		 not more than 40 mm
not more than 5 mm		 25mm
2mm
9. Slamming of the Shutter no visible impact after 25 impacts of 15 kg Pass
10. Misuse of the Shutter no permanent deformation after the test Pass
11. End Immersion no delamination after immersion 2.8%
12. Adhesion of Plies excellent Excellent
13. Glue Adhesion no delamination of the glue line Pass
14. Screw Holding Strength (kg) > 200 350
15.
Preservative Treatment		 Two Tier Treatment:
1. Lumber and Veneers are treated with preservatives
2. Glue Line is fortified with non- leachable organophosphorous compound (USA technology)		 Pass

Pass
16. Specific Gravity 0.60 0.60
17. Water Absorption < 2% 1%
18 Nail Holding Strength (kg) > 100 250
